145L
145L
- Available: 0
- Manufacturer: Hammond Manufacturing
- Part Number: 145L
- Detailed Description: 4k Impedance Primary Ohms 2.6kCT Impedance Secondary Ohms Audio Transformer 150Hz ~ 15kHz Chassis Mount
- Category: Transformers | Audio Transformers
- RoHS Status： ROHS3 Compliant
- Datasheet: Datasheet
Reference Price (USD)
1+
$30.2640
10+
$28.4482
100+
$26.9350
1000+
$25.4218
10000+
$23.9086
Considering price fluctuations, this price is only for reference. Please send RFQ to [email protected] to get the best price, thank you.
Product Specifications
| Manufacturer | Hammond Manufacturing |
|---|---|
| Series | 145 |
| Package | Bulk |
| Standard Package | 1 |
| Product Status | Active |
| Turns Ratio - Primary:Secondary | - |
| Impedance - Primary (Ohms) | 4k |
| Impedance - Secondary (Ohms) | 2.6kCT |
| DC Resistance (DCR) - Primary | 340Ohm |
| DC Resistance (DCR) - Secondary | 100Ohm |
| Transformer Type | Economical Open Type |
| Frequency Range | 150Hz ~ 15kHz |
| Frequency Response | ±1dB |
| Voltage - Isolation | - |
| Insertion Loss | - |
| Return Loss | - |
| Power Level | 135mW |
| Operating Temperature | - |
| Approval Agency | - |
| Mounting Type | Chassis Mount |
| Size / Dimension | 1.630" L x 0.880" W (41.40mm x 22.35mm) |
| Height - Seated (Max) | 0.810" (20.57mm) |
| Termination Style | Wire Leads |
| Weight | 0.088 lb (39.92 g) |
Environmental & Export
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8504.31.4035 |
